CHFCAF120PN - Type CH 3/4" Combo Afci W/Flag 1P 20A 10KAIC Plug

Eaton

$64.69 (Each)
$64.69 (Each)

Availability: Call for Availability

Buy Now

QTY:

Each

Also in stock

$64.69Each

CHFP120AF

Eaton Corp
CH Combo Afci BRKR 20A Pon 10kaic

View Item or Compare

Overview
Specifications
Current Stock
Add-On Items
Alternate Items

Overview

Thank you for your suggestions! We appreciate your assistance in improving our software. It helps us serve you even better!

Edit Mode: Please login to suggest improvements for this item.

Help Improve Our Data

Quick Specs

Catalog Number: CHFCAF120PN Vendor Code CHD
Manufacturer: Eaton
Manufacturer's Part Number: CHFCAF120PN
Description: Type CH 3/4" Combo Afci W/Flag 1P 20A 10KAIC Plug
Arc Fault Circuit Breaker, 20 A, Pigtail Terminal, Plug-On, 120/240 V Ac, 3 In Overall Height, 3.5 In Overall Length, 1 In Overall Width, 0.5 LB
Slang Terms: Suggest a New Term
Categories: Arc Fault Afci Plug - In Circuit Breakers Mark as Incorrect
Suggest a New Category
Classification: Fault Sensing Breakers (Afci/Gfci)
UNSPSC: 39121603 - Miniature circuit breakers
UPC/GTIN: 786685546209 / 00786685546209
Weight per unit: 0.5 (lbs/each)

Price & Packaging

Minimum Order Quantity: 1
Unit: $64.69 (Each)

Resources

Images
: CHFCAF120PN - Large Image
: CHFCAF120PN - Large Image
: CHFCAF120PN - Large Image
: CHFCAF120PN - Small Image
: CHFCAF120PN - Large Image
Attachments
: CHFCAF120PN - Specification Sheet
Other Links
: CHFCAF120PN - Other
: CHFCAF120PN - Other
: CHFCAF120PN - Other
Brochures
: CHFCAF120PN - Brochure

Suggest Substitute Item

Help Improve Our Data

Edit Mode: Please login to suggest improvements for this item.

Specifications

Thank you for your suggestions! We appreciate your assistance in improving our software. It helps us serve you even better!

Edit Mode: Please login to suggest improvements for this item.

Help Improve Our Data

Features

Current Rating: 20 A
Voltage Rating: 120/240 V ac
Poles: 1
interrupt rating: 10 kAIC
amperage rating: 20 A
connection: Pigtail

Dimensions and Weight

Overall Length: 3.5 in

Descriptions

Description: TYPE CH 3/4" COMBO AFCI W/FLAG 1P 20A 10KAIC PLUG
Product Type: Arc Fault Circuit Breaker
Long Description: Arc Fault Circuit Breaker, 20 A, Pigtail Terminal, Plug-On, 120/240 V ac, 3 in Overall Height, 3.5 in Overall Length, 1 in Overall Width, 0.5 lb
Features: Quick-make, quick-break switch mechanism combined with inverse time element tripping operation and trip- free handle design. Type CH circuit breakers trip to the OFF position, eliminating nuisance callbacks. The CHF family also includes a trip flag to differentiate between a trip and the breaker being turned off. The thermal-magnetic trip curve avoids nuisance tripping on mild overloads while reacting almost instantaneously to severe short-circuit conditions. Multipole breakers have internal common trip co
Short Description: 1P Arc Fault Circuit Breaker, 20 A, 120/240 VAC, Plug-on Neutral
extra long description: ETN CHFCAF120PN Eaton CH AFCI circu

Additional Information

circuit breaker type: Arc Fault Circuit Breaker
Terminal Connection Type: Pigtail
Mounting Type: Plug-On
Overall Height: 3 in
Overall Width: 1 in
Standards Met: UL Listed;HACR Rated;IGCC 4897
dimensions: 3.5000 IN X 1.0000 IN X 3.0000 IN

Manufacturer Information

Brand: EATON CUTLER-HAMMER
Manufacturers Part Number: CHFCAF120PN
GTIN: 00786685546209
UPC: 786685546209

Taxonomies, Classifications, and Categories

Type: AFCI circuit breakers
Category Description: Fault Sensing Breakers (AFCI/GFCI)

Availability

Status: Inactive

Packaging

Weight: 0.5 lb
Weight per each: 0.5
Carton: 1

Uses, Certifications, and Standards

Application: Generation - Renewable Energy - Alternative EnergyOtherGeneration - Conventional Energy - Conventional EnergyDatacenters - IT Space: CI and Hyper ConvergedMarine Vessels and Equipment - Marine Vessels and Equipment - Other
standard: UL Listed,HACR Rated
