FP3013848BLUE - SCO

FP3013848BLUE - 3/8, 2:1 Thin Wall, 48" Blue, 12 PCS

3M

  • $3.26 (Each)
  • $3.26 (Each)
  • $39.12 (Per 12)

In-Stock: 6 available locally (Nacogdoches, TX) (change location)

Buy Now
QTY:
Each
  • Help Improve Our Data
    Quick Specs
    Catalog Number
    FP3013848BLUE
    Manufacturer
    3M
    Manufacturer's Part Number
    FP-301-3/8-BLUE-4-BOX
    Description
    3/8, 2:1 Thin Wall, 48" Blue, 12 PCS
    Thin Wall Shrink Tube, Polyolefin Material, Blue, 2400 Psi Tensile Strength, 400 % Elongation At Break, 600 V, 3/8 In Cable Size, 0.187 In;4.75 MM Recovered Diameter, 0.375 In Expanded Diameter, 2:1 Shrink Ratio, -67 °F Operating Temperature, +275 °F Operating Temperature, 4 FT Length, 0.025 In Thickness, 10 Yr Shelf Life, 0.12 LB/Ea
    Slang Terms

    Suggest a New Term
    Similar Brands

    Categories
    Tape, Soldering, & Shrink Tube - Insulating Materials  Mark as Incorrect
    Suggest a New Category
    Classification
    Heat Shrink
    UNSPSC
    -
    UPC/EAN/GTIN
    00051128595893
    Weight per unit
    0.12 (lbs/each)
    Price & Packaging
    Minimum Order Quantity
    1
    Unit
    $3.26 (Each)
    Standard Packaging
    $39.12 (Per 12)
    Stock Availability
    Nacogdoches
    6 (Check another store)
    All Stores
    123
    Resources
    Images


    FP3013848BLUE - Large Image

    FP3013848BLUE - Large Image

    FP3013848BLUE - Small Image

    FP3013848BLUE - Large Image
    Specifications Sheets


    FP3013848BLUE - Specification Sheet
    MSDS Sheets


    FP3013848BLUE - MSDS Sheet

    FP3013848BLUE - MSDS Sheet
    Attachments


    FP3013848BLUE - Specification Sheet


    Suggest Substitute Item
    Help Improve Our Data
  • Help Improve Our Data
    Features
    Material
    Polyolefin
    FLEXIBLE POLYOLEFIN
    Voltage Rating
    600 V
    Conductor Size
    600 V
    Material, Color, and Finish
    Color
    Blue
    Dimensions and Weight
    Length
    4 ft
    Blue Caution
    Thickness
    0.025 in;0.64 mm
    0.025 INCH
    Width
    Packaging Quantity 12 Pieces per Case; Tensile Strength 2400 PSI; ROHS Compliant
    Descriptions
    Product Type
    Heat Shrink Tubing
    Thin Wall Shrink Tube
    Thin Wall Heat Shrink Tube
    Description
    3/8,2:1 THIN WALL,48" BLUE,12 PCS
    Long Description
    Thin Wall Shrink Tube, Polyolefin Material, Blue, 2400 psi Tensile Strength, 400 % Elongation at Break, 600 V, 3/8 in Cable Size, 0.187 in;4.75 mm Recovered Diameter, 0.375 in Expanded Diameter, 2:1 Shrink Ratio, -67 °F Operating Temperature, +275 °F Operating Temperature, 4 ft Length, 0.025 in Thickness, 10 yr Shelf Life, 0.12 lb/EA
    HEAT SHRINK TUBING, HEAT; BLUE COLOR; 600 V VOLTAGE RATING; THIN WALL; SHRINK TEMPERATURE 212 DEG F; FLEXIBLE POLYOLEFIN MATERIAL; SHRINK RATIO 2:1; MINIMUM EXPANDED DIAMETER 0.375 INCH; MAXIMUM RECOVERED DIAMETER 0.187 INCH; LENGTH 48 INCH LENGTH
    Features
    Description 3M(TM) Heat Shrink Tubing 3M FP-301 offers an excellent balance of electrical, physical and chemical properties for a wide variety of industrial and military applications. Rated for 135°C continuous operation, all 3M FP-301 tubing is split resistant, mechanically tough, easily marked and resists cold flow. 3M FP-301 tubing is rated for continuous operation at -55°C (-67°F) to 135°C (275°F), and is designed to withstand elevated temperatures to 300°C (572°F) for short periods. Minimum shrink tem
    Short Description
    3/8, 2:1 Thin Wall Heat Shrink Tube, Polyolefin, Blue, 48"
    Special Features
    3m Clear Tubing Fp-301 Provides Excellent Visibility For Component Packing;Split Resistant
    Additional Information
    SIZE 3/8 INCH; PACKAGING QUANTITY 250 PIECES PER CASE
    Commodity Description
    SPLICING & TERMINATING KITS
    Additional Information
    Tensile Strength
    2400 psi
    Elongation at Break
    400 %
    Cable Size
    3/8 in
    Maximum Recovered Diameter
    0.187 in;4.75 mm
    0.187 INCH
    Minimum Expanded Diameter
    0.375 in;9.53 mm
    0.375 INCH
    Minimum Operating Temperature
    -67 °F;-55 °C
    Maximum Operating Temperature
    +275 °F;+135 °C
    Made in USA
    Yes
    package quantity
    12 CA
    Shelf Life
    10 yr
    Standards Met
    SAE-AMS-DTL-23053/5, Class 1, Class 2;AMS-3636;AMS-3637;UL Listed File E-39100;CSA Certified CSA Certified LR38227;MIL-I-23053/5;MIL-DTL-23053;RoHS Compliant
    Shrink Ratio
    2:1
    Tie Entry
    0.187 Inch
    Insulator Type
    03448100610
    Shrink Temperature
    212 DEG F
    Connector Type
    COMPRESSION CONNECTOR, ELECTRO TIN PLATED COPPER MATERIAL; GREEN COLOR; 1.92 INCH OVERALL LENGTH; 0.88 INCH BARREL LENGTH; COPPER CONDUCTOR MATERIAL; UL 486A/486B, CSA C22.2 APPROVAL; 35 KV VOLTAGE RATING; 1 AWG CONDUCTOR SIZE; 5/16 INCH STUD SIZE
    Tie Width
    NON-METALLIC OUTLET BOX, OLD WORK TYPE; PVC MATERIAL; 2-1/4 INCH; 4-1/8 INCH; 2-3/4 INCH; 1 GANG(S); UL APPROVAL; (2) ZIP MOUNT RETAINER, EAR, WALL MOUNTING; 50 PER OUTER PACK STANDARD PACKAGE; 14 CUBIC INCH CAPACITY; (4) INTEGRAL CLAMP CABLE ENTRY
    Contents
    Thin
    Wall Type
    THIN
    Manufacturer Information
    Brand
    3M
    Minnesota Mining (3M)
    3M[T]
    Manufacturers Part Number
    FP301-3/8-48"-BLUE-12 PCS
    FP-301-3/8-BLUE-4-BOX
    sub brand
    3M(TM)
    Model
    FP-301
    Taxonomies, Classifications, and Categories
    Category Description
    HEAT SHRINK
    Type
    HEAT
    Packaging
    Weight
    0.12 lb/EA
    Weight per each
    0.12
    Carton
    1
    Package
    12
    Uses, Certifications, and Standards
    Application
    Construction;Industrial;Military
    Temperature Rating
    -55 TO 135 DEG C
    Approval
    UL, CSA
    Mounting
    UL, CSA
