FNQR20 - BUS

Also in stock

HCTR20 - 20A 600V Class CC Time Delay Small Control Fuse - Edison Fuses
$38.07Each

Edison Fuses
20A 600V Class CC Time Delay Small Control Fuse


View or Compare

FNQR20 - 20A 600V TD Class CC Fuse

Eaton Bussmann Series

  • $45.93 (Each)
  • $45.93 (Each)
  • $459.30 (Per 10)

Availablity: In Stock

QTY:
Each
  • Help Improve Our Data
    Quick Specs
    Catalog Number
    FNQR20
    Manufacturer
    Eaton Bussmann Series
    Manufacturer's Part Number
    FNQ-R-20
    Description
    20A 600V TD Class CC Fuse
    Eaton Bussmann Series FNQ-R Fuse, Current-Limiting Time-Delay Fuse, 20 A, CC, Non-Indicating, Ferrule End X Ferrule End, 12 Sec At 200%, 20 Kaic At 300 VDC, 200 Kaic At 600 V, Melamine Tube, 600 V, 300 VDC
    Slang Terms

    Suggest a New Term
    Similar Brands

    Categories
    Fuses - Small Dimension Fuses  Mark as Incorrect
    Suggest a New Category
    Classification
    Midget Fuses
    UNSPSC
    39121606 - Cartridge fuses
    UPC/EAN/GTIN
    051712497121 / 5027590449717 / 00051712497121
    Weight per unit
    0.02 (lbs/each)
    Price & Packaging
    Minimum Order Quantity
    1
    Unit
    $45.93 (Each)
    Carton
    $459.30 (Per 10)
    Resources
    Images


    FNQR20 - Small Image

    FNQR20 - Large Image

    FNQR20 - Large Image

    FNQR20 - Large Image

    FNQR20 - 360 Image
    Attachments


    FNQR20 - Specification Sheet

    FNQR20 - Specification Sheet
    Brochures


    FNQR20 - Brochure

    FNQR20 - Brochure
    Tech Bulletins


    FNQR20 - Tech Bulletin
    Other Links


    FNQR20 - Other

    FNQR20 - Other


    Suggest Substitute Item
    Help Improve Our Data
  • Help Improve Our Data
    Features
    amperage rating
    20
    interrupt rating
    200 kAIC at 600 Vac20 kAIC at 300 Vdc
    Voltage Rating
    600//300
    connection
    Ferrule End X Ferrule End
    Material
    Melamine Tube
    Material, Color, and Finish
    Color
    0.56 In Diameter X 2.00 In Length
    Style
    Open Office, Retail
    Dimensions and Weight
    Size
    13/32 In Diameter X 1-1/2 In Length
    Descriptions
    Product Type
    Class CC Time Delay Rejection Fuse
    Description
    20A 600V TD CLASS CC FUSE
    extra long description
    BUSS FNQ-R-20 CLASS CC TIME DELAY R
    Features
    Bussmann's Class CC fuses set the standard in Class CC fuse performance in the industry. Recognized for their superior performance, Bussmann has the right product for your circuit and equipment protection needs. These branch circuit rated, 600v, 200,000a IR fuses offer exceptional protection in the smallest package of any UL class of fuses. Choose from the ultimate protection provided by our Low Peak LP-CC fuses, the time delay of our FNQ-R's for your control transformer and similar control applications or
    Long Description
    Eaton Bussmann series FNQ-R fuse, Current-limiting time-delay fuse, 20 A, CC, Non-indicating, Ferrule end x ferrule end, 12 sec at 200%, 20 kAIC at 300 Vdc,200 kAIC at 600 V, Melamine tube, 600 V, 300 Vdc
    Special Features
    Rejection Style
    Additional Information
    dimensions
    0.4100 IN X 0.4100 IN X 1.5000 IN
    Response Time
    12 S at 200%
    class
    CC
    Coil Voltage
    Thermoplastic bodyTin-plated bifurcated copper terminal
    Manufacturer Information
    Brand
    COOPER BUSSMANN
    Manufacturers Part Number
    FNQ-R-20
    sub brand
    Stationary Mach Equip In Factory - RoboticsElec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMsElec Assemblies, Panels & EOEM - Elec Assemblies/Panels/EOEMs - AftermarketElec Assemblies, Panels & EOEM - Control Panels for MachinesElec Assemblies, Panels & EOEM - Panel BuildersInd Facilities & Factories - Facility: Power Distribution and ControlElec Assemblies, Panels & EOEM - Electrical Assemblies and EOEMs - Other
    GTIN
    00051712497121
    UPC
    051712497121
    Taxonomies, Classifications, and Categories
    Category Description
    MIDGET FUSES
    Type
    FUSE
    Packaging
    Weight per each
    0.02
    Carton
    10
    Uses, Certifications, and Standards
    standard
    CE Marked,RoHS Compliant
    Application
    Ind Facilities & Factories - Facility: Safety and Security Systems
