MC122STBKWH - ALF

MC122STBKWH - 12/2 WG MC STR BK/WH/GN Alu Armor

Flexible Conduit

  • $0.65 (Per Foot)
  • $0.65 (Per Foot)
  • $161.83 (Per 250 Feet)
  • $647.32 (Per 1,000 Feet)

In-Stock: 2,000 available locally (Nacogdoches, TX) (change location)

QTY:
Feet
  • Help Improve Our Data
    Quick Specs
    Catalog Number
    MC122STBKWH
    Manufacturer
    Flexible Conduit
    Manufacturer's Part Number
    69114701
    Description
    12/2 WG MC STR BK/WH/GN Alu Armor
    Aluminum Armored Conductor, Stranded, 19 Strands, #12 Awg Conductor Size, PVC Jacket Material, Thermoplastic Nylon Insulation Material, Copper Conductor Material, 600 V, 20 A, Black, White and Green, 2 Conductors, 250 FT Overall Length, 0.494 In Outside Diameter, +90 °C Operating Temperature, 110 LB/MFT
    Slang Terms

    Suggest a New Term
    Similar Brands

    Categories
    Armored Cable - BX - Ac - MC - Alum Armor Copper Conductors  Mark as Incorrect
    Suggest a New Category
    Classification
    BX & MC
    UNSPSC
    26121614 - Building cable
    UPC/GTIN
    032886347559 / 00032886347559
    Weight per unit
    0.11 (lbs/ft)
    Price & Packaging
    Minimum Order Quantity
    Foot
    Unit
    $0.65 (Per Foot)
    Carton
    $161.83 (Per 250 Feet)
    Stock Availability
    Nacogdoches
    2,000 Feet (Check another store)
    All Stores
    89,750 Feet
    Resources
    Images


    MC122STBKWH - Small Image

    MC122STBKWH - Large Image
    Specifications Sheets


    MC122STBKWH - Specification Sheet
    Attachments


    MC122STBKWH - Specification Sheet


    Suggest Substitute Item
    Help Improve Our Data
  • Help Improve Our Data
    Features
    Conductor Size
    #12 AWG
    12 AWG
    Current Rating
    20 A
    20 AMPERE
    Number of Conductors
    2
    2 A
    Voltage Rating
    600 V
    Stranding
    19 STRANDS
    Material, Color, and Finish
    Insulation Material
    Thermoplastic Nylon
    THHN/THWN
    Conductor Material
    Copper
    SOFT DRAWN COPPER
    Color
    Black;White;Green
    Jacket Material
    PVC
    Color Code
    BLACK/WHITE/GREEN
    Armor Material
    LIGHTWEIGHT ALUMINUM
    Dimensions and Weight
    Overall Length
    250 ft
    Outer Diameter
    0.494 INCH
    Length
    250 FT
    Length in ft
    250 VAC
    Descriptions
    Product Type
    Metal Clad Cable
    Aluminum Armored Conductor
    Long Description
    Aluminum Armored Conductor, Stranded, 19 Strands, #12 AWG Conductor Size, PVC Jacket Material, Thermoplastic Nylon Insulation Material, Copper Conductor Material, 600 V, 20 A, Black, White and Green, 2 Conductors, 250 ft Overall Length, 0.494 in Outside Diameter, +90 °C Operating Temperature, 110 lb/mft
    ALUMINUM INTERLOCKED ARMOR COPPER MC CABLE, MC; 600 V VOLTAGE RATING; 20 AMPERE CURRENT RATING; CONDUCTOR MATERIAL SOFT DRAWN COPPER; 12 AWG CONDUCTOR; 2 CONDUCTOR(S); 19 STRANDS; PVC JACKET; LIGHTWEIGHT ALUMINUM ARMOR; THHN/THWN INSULATION MATERIAL
    12-2 CU STR THHN BLK/WHT/GRN AL MC
    Short Description
    Aluminum Armored Conductor, Stranded, 12/3 AWG with ground, PVC Jacket, 250 ft
    Description
    12/2 WG MC STR BK/WH/GN ALU ARMOR
    Commodity Description
    ALUM ARMOR CU CONDCTOR-AC90-CORFLEX
    Additional Information
    Solid/Strand
    Stranded
    Number of Strands
    19
    outside diameter
    0.494 in
    Maximum Operating Temperature
    +90 °C
    Standards Met
    RoHS Compliant;Federal Specification A-A-59544;IEEE 1202;NEC;UL 83;UL1569;UL1685
    Made in USA
    Yes
    Ground Conductor Type
    12 AWG GREEN INSULATED
    Manufacturer Information
    Brand
    Flexible Conduit
    SOUTHWIRE
    SOUTHWIRE COMPANY
    Manufacturers Part Number
    69114701
    GTIN
    00032886347559
    UPC
    032886347559
    Taxonomies, Classifications, and Categories
    Category Description
    BX & MC
    Type
    RoHS Compatible; Applicable Standard Federal Specification A-A-59544, IEEE 1202, NEC
    Packaging
    Weight
    110 lb/mft
    110 LB/MFT
    Package Type
    Coil
    COIL
    Weight per foot
    0.11
    Carton
    250
    Uses, Certifications, and Standards
    Application
    Commercial;Industrial;Institutional;Multi-Residential Buildings
    Temperature Rating
    75 DEG C (WET), 90 DEG C (DRY)
    Approval
    UL 83, UL 1569
