GMA1R - BUS

GMA1R - 1A 250V Fa 5X20MM Glass Fuse

Eaton

  • $2.10 (Each)
  • $2.10 (Each)
  • $10.50 (Per 5)

Availablity: In Stock

QTY:
Each
  • Help Improve Our Data
    Quick Specs
    Catalog Number
    GMA1R
    Manufacturer
    Eaton
    Manufacturer's Part Number
    GMA-1-R
    Description
    1A 250V Fa 5X20MM Glass Fuse
    Fuse, Fast Acting Fuse Speed, 60 Min @ 135%;2 Min @ 200 % Response Time, Ferrule End X Ferrule End Connection, 1 A, 250 V Ac, Glass (Body);Brass( End Cap) Material, Ferrule Terminal, 5.2 MM Diameter, 20 MM Overall Length
    Slang Terms

    Suggest a New Term
    Similar Brands

    Categories
    Fuses - Small Dimension Fuses  Mark as Incorrect
    Suggest a New Category
    Classification
    Glass Fuses (and Ceramic)
    UNSPSC
    39121607 - Glass body fuses
    UPC/EAN/GTIN
    051712647830 / 5027590501699 / 00051712647830
    Weight per unit
    0.002 (lbs/each)
    Price & Packaging
    Minimum Order Quantity
    1
    Unit
    $2.10 (Each)
    Carton
    $10.50 (Per 5)
    Resources
    Images


    GMA1R - Small Image

    GMA1R - Large Image

    GMA1R - Large Image

    GMA1R - Large Image

    GMA1R - Large Image
    Specifications Sheets


    GMA1R - Specification Sheet
    Attachments


    GMA1R - Specification Sheet

    GMA1R - Specification Sheet

    GMA1R - Specification Sheet

    GMA1R - Specification Sheet
    Brochures


    GMA1R - Brochure

    GMA1R - Brochure

    GMA1R - Brochure
    Other Links


    GMA1R - Other


    Suggest Substitute Item
    Help Improve Our Data
  • Help Improve Our Data
    Features
    Current Rating
    1 A
    Voltage Rating
    250 V ac
    Material
    Glass (Body);Brass( End Cap)
    Terminal Type
    Ferrule
    interrupt rating
    35 A @ 250 V ac;10000 A @ 125 V ac
    amperage rating
    1.0000 IN X 1.0000 IN X 2.2300 IN
    connection
    Ferrule End X Ferrule End
    Material, Color, and Finish
    Color
    Non-Indicating
    Style
    Not Applicable
    Dimensions and Weight
    Diameter
    5.2 mm
    Overall Length
    20 mm
    Size
    Interrupt Rating 200 Amp at 250 Vac, 10000 Amp at 125 Vac/Vdc, Material Ceramic Tube, Nickel Plated Brass Endcap
    Descriptions
    Description
    1A 250V FA 5X20MM GLASS FUSE
    extra long description
    BUSS GMA-1-R GMA 1A BUSS FUSE
    Product Type
    Fuse
    Long Description
    Fuse, Fast Acting Fuse Speed, 60 min @ 135%;2 min @ 200 % Response Time, Ferrule End x Ferrule End Connection, 1 A, 250 V ac, Glass (Body);Brass( End Cap) Material, Ferrule Terminal, 5.2 mm Diameter, 20 mm Overall Length
    Short Description
    1 A, 250 VAC, Fast Acting Fuse, Low-Break IEC Glass
    Special Features
    1
    Features
    Fast-acting, glass tube 5 mm x 20 mm ferrule fuse designed to UL 248-14 for overcurrent protection of electronic circuits. Install into a Bussmann Series fuse holder, block or fuse clip. Also available with axial leads for thru-hole installation Eatons GMA fast-acting, glass tube 5mm x 20mm ferrule fuses are designed to UL 248-14 for overcurrent protection of electronic circuits. Order in cartridge fuse format and install into a Bussmann Series fuse holder, block, or fuse clip, or purchase with available
    Additional Information
    Fuse Speed
    Fast Acting
    Response Time
    60 min @ 135%;2 min @ 200 %
    Connection Type
    Ferrule End x Ferrule End
    Standards Met
    UL Listed;Guide JDYX;File E19180;UL Listed;Guide JDYX2;File E19180;CSA Certified;Class 1422-01;File 53787;PSE Approval
    package quantity
    5 CT
    class
    0.56 In Diameter X 2.00 In Length
    dimensions
    0.7874 IN X 0.1969 IN X 0.1969 IN
    type of indicators
    Non-Indicating
    Coil Voltage
    Thermoplastic bodyTin-plated bifurcated copper terminal
    Manufacturer Information
    Brand
    Eaton Bussmann series
    Manufacturers Part Number
    GMA-1-R
    sub brand
    Stationary Mach Equip In Factory - RoboticsElec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMsElec Assemblies, Panels & EOEM - Elec Assemblies/Panels/EOEMs - AftermarketElec Assemblies, Panels & EOEM - Control Panels for MachinesElec Assemblies, Panels & EOEM - Panel BuildersInd Facilities & Factories - Facility: Power Distribution and ControlElec Assemblies, Panels & EOEM - Electrical Assemblies and EOEMs - Other
    GTIN
    00051712647830
    UPC
    051712647830
    Taxonomies, Classifications, and Categories
    Category Description
    GLASS FUSES (and ceramic)
    Type
    Fast-Acting Fuse
    Trade Size
    Trade Size
    1 A
    Packaging
    Weight per each
    0.002
    Carton
    5
    Uses, Certifications, and Standards
    Application
    Electronic Circuits
    standard
    RoHS Compliant,CE Marked
