TCF60 - BUS

TCF60 - 60A 600V Finger Safe Class J Fuse

Eaton Bussmann Series

  • $89.71 (Each)
  • $89.71 (Each)
  • $1,076.52 (Per 12)

Availablity: Out of Stock

QTY:
Each
  • Help Improve Our Data
    Quick Specs
    Catalog Number
    TCF60
    Manufacturer
    Eaton Bussmann Series
    Manufacturer's Part Number
    TCF60
    Description
    60A 600V Finger Safe Class J Fuse
    Eaton Bussmann Series TCF Fuse, 60 A, 60 HZ, 50 HZ, Dual, CF, Black, With Indicator, Blade End, Time Delay, 10 Sec At 500%, 300 Kaic At 600 V, 100 Kaic At 300 VDC, Glass Filled Pes, Chassis, 35 MM Din Rail, 600 V, 300 VDC
    Slang Terms

    Suggest a New Term
    Similar Brands

    Categories
    Distribution Fuses - Dual Element  Mark as Incorrect
    Suggest a New Category
    Classification
    Fuses & Fuse Accessories
    UNSPSC
    39121606 - Cartridge fuses
    UPC/EAN/GTIN
    051712615082 / 5027590184441 / 00051712615082
    Weight per unit
    0.18 (lbs/each)
    Price & Packaging
    Minimum Order Quantity
    1
    Unit
    $89.71 (Each)
    Carton
    $1,076.52 (Per 12)
    Resources
    Images


    TCF60 - Small Image

    TCF60 - Large Image

    TCF60 - Large Image

    TCF60 - Large Image
    Attachments


    TCF60 - Specification Sheet

    TCF60 - Specification Sheet

    TCF60 - Specification Sheet
    Brochures


    TCF60 - Brochure
    Tech Bulletins


    TCF60 - Tech Bulletin
    Other Links


    TCF60 - Other


    Suggest Substitute Item
    Help Improve Our Data
  • Help Improve Our Data
    Features
    interrupt rating
    300 kAIC at 600 Vac100 kAIC at 300 Vdc
    amperage rating
    60
    Voltage Rating
    600//300
    connection
    Blade End
    Material
    Glass Filled PES
    Dimensions and Weight
    Size
    2.13 In Length X 1.00 In Height
    Descriptions
    Description
    60A 600V FINGER SAFE CLASS J FUSE
    Long Description
    Eaton Bussmann series TCF fuse, 60 A, 60 Hz, 50 Hz, Dual, CF, Black, With Indicator, Blade end, Time delay, 10 sec at 500%, 300 kAIC at 600 V,100 kAIC at 300 Vdc, Glass filled PES, Chassis,35 mm DIN rail, 600 V, 300 Vdc
    Features
    The revolutionary BussmannTM series Low-PeakTM CUBEFuseTM delivers the smallest footprint compared to any Class CC, J or RK fuse solution  requiring up to 70% less space when combined with its unique fuse holder or UL 98 Listed Compact Circuit Protector switch. Freeing up space is powerful. And the CUBEFuse does just that, while packing up to a 300 kA interrupting rating and enabling higher equipment short-circuit current rating (SCCR). Available from 1 to 400 amps.
    Special Features
    Finger Safe
    Product Type
    Cubefuse, TCF 60A Ind
    Additional Information
    Response Time
    10 S at 500%
    dimensions
    2.1300 IN X 1.0000 IN X 1.9000 IN
    class
    Class CF
    element
    Dual
    Manufacturer Information
    Brand
    Eaton
    sub brand
    Bussmann series
    Manufacturers Part Number
    TCF60
    GTIN
    00051712615082
    UPC
    051712615082
    Taxonomies, Classifications, and Categories
    Type
    FUSE
    Category Description
    Fuses & Fuse Accessories
    Packaging
    Weight per each
    0.18
    Carton
    12
    Uses, Certifications, and Standards
    Mounting
    35 mm DIN Rail, Chassis
    Application
    Ind Facilities & Factories - Facility: Safety and Security SystemsDatacenters - Facilities: Power DistributionCommercial / Institutional Buildings / Structures - Critical PowerInd Facilities & Factories - Facility: Power Distribution and ControlStationary Machinery and Equipment Outside Factory - HVAC
    standard
    UL Listed,CSA Certified,CE Marked,RoHS Compliant
