A808CH - HOF

A808CH - 8X8X4 N12 CH CLMP CVR

Nvent Hoffman

  • $85.30 (for 1 Each)
  • $85.30 (1 Each)

In-Stock: 4 available locally (Nacogdoches, TX) (change location)

QTY:
Each
  • Help Improve Our Data
    Quick Specs
    Catalog Number
    A808CH
    Manufacturer
    Nvent Hoffman
    Manufacturer's Part Number
    A808CH
    Description
    8X8X4 N12 CH CLMP CVR
    Junction Box, Steel, Type 12 Continuous Hinge, Bracket Mount, Gray, Polyester Powder Paint, 8 In Overall Width, 8 In Overall Length, 4 In Overall Height, 6.82 LB
    Slang Terms

    Suggest a New Term
    Similar Brands

    Categories
    Metal Enclosures & Cabinets - Nema Types 12 & 13 Metallic En  Mark as Incorrect
    Suggest a New Category
    Classification
    Steel Junction Boxes
    UNSPSC
    39121303 - Electrical boxes
    UPC/GTIN
    783510548605 / 00783510548605
    Weight per unit
    6.82 (lbs/each)
    Price & Packaging
    Minimum Order Quantity
    1 Each
    Unit
    $85.30 (1 Each)
    Stock Availability
    Nacogdoches
    4 Each (Check another store)
    All Stores
    128 Each
    Resources
    Installation Sheets


    A808CH - Installation Sheet
    Attachments


    A808CH - Specification Sheet

    A808CH - Specification Sheet
    Images


    A808CH - Small Image

    A808CH - Large Image

    A808CH - Large Image
    Other Links


    A808CH - Other

    A808CH - Other

    A808CH - Other


    Suggest Substitute Item
    Help Improve Our Data
  • Help Improve Our Data
    Features
    Material
    Steel
    Steel IN
    Cover Type
    Type 12 Continuous Hinge
    Material, Color, and Finish
    Color
    Gray 0
    Dimensions and Weight
    Overall Length
    8 in;203 mm
    Size
    8.00x8.004.00 in
    Descriptions
    Description
    8X8X4 N12 CH CLMP CVR
    Product Type
    CH Box 8.00X8.00X4.00
    Junction Box
    Special Features
    Continuously Welded and Ground Smooth Continuous Hinge;Screw-Down Door Clamps;Bonding Provision on Door;External Welded-On Mounting Brackets for Easy Installation;Oil-Resistant Gasket;Weldnuts Provided for Mounting Option
    16 or 14 gauge steel, Seams continuously welded and ground smooth, Continuous hinge, Screw-down door clamps, Bonding provision on door, External welded-on mounting brackets for easy installation, Oil-resistant gasket, Weldnuts provided for mounting optional panels and terminal block kits in size 6.00 x 4.00 in. (152 x 102 mm) and larger
    Long Description
    Junction Box, Steel, Type 12 Continuous Hinge, Bracket Mount, Gray, Polyester Powder Paint, 8 in Overall Width, 8 in Overall Length, 4 in Overall Height, 6.82 lb
    Short Description
    8X8X4 N12 Junction Box, Steel, Gray
    Additional Information
    Mounting Type
    Bracket Mount
    Finish/Coating
    Polyester Powder Paint
    ip rating
    IP65
    Overall Width
    8 in;203 mm
    Overall Height
    4 in;102 mm
    Enclosure Type
    NEMA 12/13
    Standards Met
    UL 50, 50E Listed, TYPE 12, 13, FILE NO. E27567;cUL Listed per CSA 22.2 NO. 94, Type 12, 13, FILE NO. E27567;UL 508A Listed, Type 12, 13, FILE NO. E61997;cUL Listed per CSA 22.2 NO. 94, Type 12, 13, FILE NO. E61997
    Made in USA
    Yes
    Manufacturer Information
    Brand
    Hoffman Enclosures, Inc.
    Nvent Hoffman
    J-Series
    Manufacturers Part Number
    A808CH
    sub brand
    Hoffman
    GTIN
    00783510548605
    UPC
    783510548605
    Taxonomies, Classifications, and Categories
    Category Description
    STEEL JUNCTION BOXES
    Type
    Continuous Hinge with Clamps, Type 12
    Packaging
    Weight
    6.82 lb
    Weight per each
    6.82
    Carton
    1
    Uses, Certifications, and Standards
    Application
    This Easy-To-Open Continuous Hinge Enclosure Features Screw-Down Clamps for Secure Closure
    This easy-to-open, continuous hinge enclosure features screw-down clamps for secure closure and can be used in a wide variety of applications.
    standard
    UL 50, 50E Listed, Type 12, 13, File No. E27567, cUL Listed per CSA 22.2 No. 94, Type 12, 13, File No. E27567, UL 508A Listed, Type 12, 13, File No. E61997, cUL Listed per CSA 22.2 No. 94, Type 12, 13, File No. E61997, NEMA/EEMAC Type 12 and 13, CSA, File
