2087W - PAS

2087W - Radiant Dead FRNT Self Test Gfci 20A WH

Legrand-Pass & Seymour

  • $37.52 (Each)
  • $37.52 (Each)
  • $375.20 (Per 10)

Availablity: In Stock

QTY:
Each
  • Help Improve Our Data
    Quick Specs
    Catalog Number
    2087W
    Manufacturer
    Legrand-Pass & Seymour
    Manufacturer's Part Number
    2087W
    Description
    Radiant Dead FRNT Self Test Gfci 20A WH
    Self-Test Gfci Receptacle Receptacle, 20 A, 125 V, 2 Poles, #14 to #10 Awg Compatible Wire Size, Control Circuit Actuator, Back and Side Wired Connection, 60 HZ, 1.73 In Width, 4.20 In Height, Thermoplatic Material, White, 0.025 Sec Trip Time, Impact Resistant, 0.2800 LB
    Slang Terms

    Suggest a New Term
    Similar Brands

    Categories
    Gen Purpose Wiring Devices - Gen Purpose Recept & Surge Pro  Mark as Incorrect
    Suggest a New Category
    Classification
    Residential Switches
    UNSPSC
    39121633 - Circuit interruptor
    UPC/GTIN
    785007035803 / 00785007035803
    Weight per unit
    0.275 (lbs/each)
    Price & Packaging
    Minimum Order Quantity
    1
    Unit
    $37.52 (Each)
    Standard Packaging
    $375.20 (Per 10)
    Resources
    Images


    2087W - Large Image

    2087W - Small Image

    2087W - Large Image
    Attachments


    2087W - Specification Sheet
    Other Links


    2087W - Other


    Suggest Substitute Item
    Help Improve Our Data
  • Help Improve Our Data
    Features
    Current Rating
    20 A
    Material
    Thermoplatic
    Voltage Rating
    125
    Poles
    2
    amperage rating
    20
    interrupt rating
    4 to 6 mA
    connection
    Back and side wire
    actuator
    Control Circuit
    Material, Color, and Finish
    Color
    White
    Dimensions and Weight
    Height
    4.20 in
    Length
    1.03
    Width
    1.73
    Descriptions
    Product Type
    Self-Test Gfci Receptacle Receptacle
    Self-Test GFCI Receptacle Receptacle
    Short Description
    20 A, 125 V, Self-Test Gfci Receptacle Receptacle, White
    Special Features
    20 Amp Feed-Thru Capacity
    Long Description
    Self-Test GFCI Receptacle Receptacle, 20 A, 125 V, 2 Poles, #14 to #10 AWG Compatible Wire Size, Control Circuit Actuator, Back and Side Wired Connection, 60 Hz, 1.73 in Width, 4.20 in Height, Thermoplatic Material, White, 0.025 sec Trip Time, Impact Resistant, 0.2800 lb
    Features
    The radiant(R) collection is a step up from the standard with simple, classic options in wiring devices, home automation controls and screwless wall plates that complement today's homes.The self-test GFCI conducts an automatic test every three seconds, ensuring it's always ready to protect. If the device fails the test, the indicator light flashes to signal that the GFCI should be replaced. It also has our proven SafeLock(TM) Protection feature: if critical components are damaged and protection is lost, po
    Description
    RADIANT DEAD FRNT SELF TEST GFCI 20A WH
    Additional Information
    Receptacle Type
    Self Test GFCI
    Compatible Wire Size
    #14 to #10 AWG
    actuator type
    Control Circuit
    Connection Type
    Back and Side Wired
    Trip Time
    0.025 sec
    Resistance Properties
    Impact Resistant
    package quantity
    1 CT;10 PK
    Standards Met
    cULus Listed;UL Listed;fsUL Listed;UL 94 v2;UL498;Federal Specifications
    Trip Type
    .025 Second Nominal
    trip range
    4 to 6 mA
    Manufacturer Information
    Brand
    PASS & SEYMOUR
    Manufacturers Part Number
    2087W
    sub brand
    Pass & Seymour
    GTIN
    00785007035803
    UPC
    785007035803
    Taxonomies, Classifications, and Categories
    Category Description
    Residential Switches
    Type
    Specification Grade Dead-Front 20A Self-Test GFCI Receptacle
    Packaging
    Weight
    0.2800 lb
    Weight per each
    0.275
    Carton
    1
    Package
    10
    Uses, Certifications, and Standards
    nema rating
    5-15R
    Frequency Rating
    60 Hz
    Application
    Residential;Commercial
    Operating Temperature
    -35°C to +66°C
    environmental conditions
    95% Humidity, UL 94 V2
    standard
    cULus, UL Listed, FSUL
