5662 - PAS

5662 - 15A 250V Turnlok Rec L615

Legrand-Pass & Seymour

  • $27.76 (for 1 Each)
  • $27.76 (1 Each)
  • $277.60 (10 Each)

In-Stock: 0 available locally (Nacogdoches, TX) (change location)

QTY:
Each
  • Help Improve Our Data
    Quick Specs
    Catalog Number
    5662
    Manufacturer
    Legrand-Pass & Seymour
    Manufacturer's Part Number
    5662
    Description
    15A 250V Turnlok Rec L615
    Duplex Receptacle, 15 A, 250 V Ac, 2 Poles, 3 Wires, #14 to #10 Awg Compatible Wire Size, Back and Side Wired Connection, Wall Mount, 1.322 In Length, 0.780 In Width, 3.281 In Height, Nylon Material, Brown, 0.2100 LB
    Slang Terms

    Suggest a New Term
    Similar Brands

    Categories
    Gen Purpose Wiring Devices - Gen Purpose Recept & Surge Pro  Mark as Incorrect
    Suggest a New Category
    Classification
    Residential Recepticals
    UNSPSC
    39121406 - Electrical receptacles
    UPC/GTIN
    785007566208 / 00785007566208
    Weight per unit
    0.21 (lbs/each)
    Price & Packaging
    Minimum Order Quantity
    1 Each
    Unit
    $27.76 (1 Each)
    Standard Packaging
    $277.60 (10 Each)
    Stock Availability
    Nacogdoches
    0 Each (Find nearest stock)
    All Stores
    4 Each
    Resources
    Attachments


    5662 - Specification Sheet

    5662 - Specification Sheet

    5662 - Specification Sheet
    Images


    5662 - Small Image

    5662 - Large Image

    5662 - Large Image

    5662 - Large Image
    Installation Sheets


    5662 - Installation Sheet
    Brochures


    5662 - Brochure
    Other Links


    5662 - Other


    Suggest Substitute Item
    Help Improve Our Data
  • Help Improve Our Data
    Features
    Current Rating
    15 A
    Voltage Rating
    250 V ac
    250 VAC
    Number of Wires
    3
    3 in
    Material
    Nylon
    NYLON
    Wire Size
    #14 - #10 Awg
    amperage rating
    15 A
    Poles
    2 in
    connection
    Back and side wire
    Material, Color, and Finish
    Color
    Brown
    BROWN
    Dimensions and Weight
    Length
    1.322 in
    Width
    0.780 in
    Height
    3.281 in
    Size
    1.322 L x .780 W x 3.281 H In
    Descriptions
    Product Type
    Recp Dup 15A 250V S+B Wire
    Duplex Receptacle
    Description
    15A 250V TURNLOK REC L615
    Long Description
    Duplex Receptacle, 15 A, 250 V ac, 2 Poles, 3 Wires, #14 to #10 AWG Compatible Wire Size, Back and Side Wired Connection, Wall Mount, 1.322 in Length, 0.780 in Width, 3.281 in Height, Nylon Material, Brown, 0.2100 lb
    Features
    Heavy-Duty Spec Grade Duplex Receptacle Back & Side Wire 15amp 250volt Brown
    Short Description
    15 A, 250 VAC, Duplex Receptacle, Brown
    Special Features
    Heavy-Duty;Brass Strap for Added Strength and Ground Conductivity. 0.032 in Thick;Brass;Triple-Wipe Power Contacts for Lasting Retention;Strap Tabs Wrap Around Face to Prevent Strap From Separating From Face and Back Body;Easily Accessed Break-Off
    Heavy-duty, brass strap for added strength and ground conductivity. .032 inch thick, brass, triple-wipe power contacts for lasting retention. Strap tabs wrap around face to prevent strap from separating from face and back body. Easily accessed break-off, line-contact connecting tab for fast, easy split-circuit wiring. High strength nylon face. Internal screw-pressure-plate back and side wired to accept #14 – #10 AWG stranded or solid copper or copper-clad conductors. Eight back wire holes. Auto-ground clip
    Additional Information
    Receptacle Type
    Duplex
    Compatible Wire Size
    #14 to #10 AWG
    Connection Type
    Back and Side Wired
    Mounting Type
    Wall Mount
    package quantity
    1 CT;10 PK
    Standards Met
    cULus Listed;UL 498;CSA c22.2 no. 42;UL 94 v2;RoHS Compliant;Federal Specifications
    Dielectric Strength
    Withstands 2000V minimum
    Manufacturer Information
    Brand
    Pass & Seymour/Legrand
    LEGRAND-PASS & SEYMOUR
    Pass and Seymour
    Radiant
    Manufacturers Part Number
    5662
    sub brand
    Pass & Seymour
    GTIN
    00785007566208
    UPC
    785007566208
    Taxonomies, Classifications, and Categories
    Category Description
    Residential recepticals
    Type
    Spec Grade Receptacle, Heavy-Duty
    Packaging
    Weight
    0.2100 lb
    Weight per each
    0.21
    Carton
    1
    Package
    10
    Uses, Certifications, and Standards
    Application
    Commercial
    COMMERCIAL
    nema rating
    6-15R
    standard
    cULus UL498, CSA C22.2 No. 42
    environmental conditions
    Flammability: UL94 V2
    Temperature Rating
    Temperature Rise: Maximum 30°C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature: Maximum continuous +60°C, minimum -40°C without impact
    Mounting
    WALL
