14RB8E - TAB

14RB8E - 18-14 Ring Terminal

Sta-Kon

  • $42.27 (Per 100)
  • $0.42 (Each)
  • $42.27 (Per 100)
  • $422.70 (Per 1,000)
  • $2,113.50 (Per 5,000)

Availablity: In Stock

Buy Now
QTY:
Each
  • Help Improve Our Data
    Quick Specs
    Catalog Number
    14RB8E
    Manufacturer
    Sta-Kon
    Manufacturer's Part Number
    14RB-8
    Description
    18-14 Ring Terminal
    Vinyl-Insulated Ring Terminal, Length .97 Inches, Width .31 Inches, Maximum Insulation .170, Bolt Hole #8, Wire Range #18-#14 Awg, Color Blue, Copper, Tin Plated
    Slang Terms

    Suggest a New Term
    Similar Brands

    Categories
    Solderless Connectors - Small Terminals & Connectors  Mark as Incorrect
    Suggest a New Category
    Classification
    Sta-Kon Type Terminals
    UNSPSC
    39121432 - Electrical terminals
    UPC/EAN/GTIN
    786210800653 / 5414363138044 / 00786210800653
    Weight per unit
    0.003 (lbs/each)
    Price & Packaging
    Minimum Order Quantity
    100
    Unit
    $0.42 (Each)
    Carton
    $422.70 (Per 1,000)
    Standard Packaging
    $2,113.50 (Per 5,000)
    Resources
    Images


    14RB8E - Small Image

    14RB8E - Large Image

    14RB8E - Large Image

    14RB8E - Large Image

    14RB8E - Large Image

    14RB8E - Large Image
    Attachments


    14RB8E - Specification Sheet

    14RB8E - Specification Sheet

    14RB8E - Specification Sheet

    14RB8E - Specification Sheet

    14RB8E - Specification Sheet
    Other Links


    14RB8E - Other

    14RB8E - Other

    14RB8E - Other

    14RB8E - Other

    14RB8E - Other


    Suggest Substitute Item
    Help Improve Our Data
  • Help Improve Our Data
    Features
    Wire Size
    18-14 AWG
    Voltage Rating
    600 V ac
    Material
    Copper
    Terminal Type
    Ring Terminal
    Material, Color, and Finish
    Color
    Blue
    Insulation Material
    Vinyl
    Conductor Material
    Copper
    Insulation Color
    Blue
    Dimensions and Weight
    Overall Length
    0.97 in
    Descriptions
    Description
    18-14 RING TERMINAL
    Long Description
    Ring Terminal, #18 AWG Conductor Size, #14 AWG Conductor Size, Insulated, Vinyl Insulation Material, Copper Conductor Material, Blue Insulation Color, 600 V ac, 0.97 in Overall Length, 0.170 in Insulation Length, 0.003 lb
    Special Features
    These Terminals are Self-Insulated With a PVC Insulation Sleeve Of Extra Length to Give Protection and Relieve Bending Stress at Wires Flex Point. Brazed Seam Barrel Is Serrated to Obtain High Pull-Out Value.
    Product Type
    Ring Terminal
    Features
    Vinyl-Insulated Ring Terminal, Length .97 Inches, Width .31 Inches, Maximum Insulation .170, Bolt Hole #8, Wire Range #18-#14 AWG, Color Blue, Copper, Tin Plated.
    Short Description
    #18 to #14 AWG Sta-Kon Ring Terminal, Insulated, 600 VAC, Bolt Hole #8
    extra long description
    TB 14RB-8 INS VINYL RING TERM 18-14
    Additional Information
    Minimum Conductor Size
    #18 AWG
    Maximum Conductor Size
    #14 AWG
    Insulated/Non-Insulated
    Insulated
    Insulation Length
    0.170 in
    Standards Met
    UL E9809;CSA
    Made in USA
    yes
    package quantity
    1000 CT;5000 PK
    Manufacturer Information
    Brand
    Sta-Kon
    Manufacturers Part Number
    14RB-8
    sub brand
    Sta-Kon
    GTIN
    00786210800653
    UPC
    786210800653
    Taxonomies, Classifications, and Categories
    Category Description
    STA-KON TYPE TERMINALS
    Type
    Vinyl Insulated Ring Terminal
    Availability
    minimum qty
    100
    Packaging
    Weight
    0.003 lb
    Weight per each
    0.003
    Carton
    1000
    Package
    5000
    Uses, Certifications, and Standards
    Application
    Wire Termination
    standard
    UL E9809
    Help Improve Our Data
