54136 - TAB

54136 - 6AWG Blue 1H Cop Lug

Color-Keyed

  • $1.70 (for 1 Each)
  • $1.70 (1 Each)
  • $84.78 (50 Each)
  • $169.56 (100 Each)
  • $847.80 (500 Each)

In-Stock: 0 available locally (Nacogdoches, TX) (change location)

QTY:
Each
  • Help Improve Our Data
    Quick Specs
    Catalog Number
    54136
    Manufacturer
    Color-Keyed
    Manufacturer's Part Number
    54136
    Description
    6AWG Blue 1H Cop Lug
    Standard Barrel Single Hole Compression Lug, #6 Awg Conductor Size, Non-Insulated, Copper Conductor Material, Blue (Die Color) Insulation Color, 1.41 In Overall Length, Tongue Terminal, 35 KV, 0.13 LB/Ea
    Slang Terms

    Suggest a New Term
    Similar Brands

    Categories
    Solderless Connectors - Large Terminals & Connectors  Mark as Incorrect
    Suggest a New Category
    Classification
    Comp & Mech Lugs and Butt Splices
    UNSPSC
    39121405 - Cable or wire lug
    UPC/EAN/GTIN
    786210541365 / 5414363110453 / 00786210541365
    Weight per unit
    0.125 (lbs/each)
    Price & Packaging
    Minimum Order Quantity
    1 Each
    Unit
    $1.70 (1 Each)
    Carton
    $84.78 (50 Each)
    Standard Packaging
    $847.80 (500 Each)
    Stock Availability
    Nacogdoches
    0 Each (Find nearest stock)
    All Stores
    3,521 Each
    Resources
    Images


    54136 - Large Image

    54136 - Large Image

    54136 - Small Image

    54136 - Large Image
    Installation Sheets


    54136 - Installation Sheet

    54136 - Installation Sheet

    54136 - Installation Sheet
    Attachments


    54136 - Specification Sheet

    54136 - Specification Sheet

    54136 - Specification Sheet

    54136 - Specification Sheet
    Other Links


    54136 - Other

    54136 - Other

    54136 - Other


    Suggest Substitute Item
    Help Improve Our Data
  • Help Improve Our Data
    Features
    Material
    COPPER
    Voltage Rating
    Max 35kV
    insulation
    None IN
    Terminal Type
    Tongue
    Material, Color, and Finish
    Color
    Blue Light
    Conductor Material
    Copper
    Insulation Color
    Blue (Die Color)
    Dimensions and Weight
    Overall Length
    1.41 in
    Descriptions
    Long Description
    Standard Barrel Single Hole Compression Lug, #6 AWG Conductor Size, Non-Insulated, Copper Conductor Material, Blue (Die Color) Insulation Color, 1.41 in Overall Length, Tongue Terminal, 35 kV, 0.13 lb/EA
    Features
    Two-way connectors provide high pullout values, are easy to insulate and provide a low-resistance connection of high quality and low installed cost.
    Product Type
    Standard Barrel Single Hole Compression Lug
    #6 STD BRL. 1 Hole 3/8 Bolt
    Short Description
    Standard Barrel Single Hole Compression Lug, Non-Insulated, 1.41 in L, 35 kV
    Special Features
    Standard Barrel;High Conductivity
    Description
    6AWG BLUE 1H COP LUG
    Additional Information
    Number of Holes
    1 PH
    Stud Size
    3/8 IN
    Cable Size
    6 AWG
    Maximum Conductor Size
    #6 AWG
    For Stud Size
    3/8 in
    Insulated/Non-Insulated
    Non-Insulated
    for use with
    Copper Conductor
    Maximum Voltage Rating
    35 kV
    Standards Met
    UL Listed E9809;CSA Certified
    package quantity
    50 CT;500 PK
    Manufacturer Information
    Brand
    Thomas & Betts
    COLOR-KEYED
    sub brand
    Color-Keyed
    Manufacturers Part Number
    54136
    GTIN
    00786210541365
    UPC
    786210541365
    Taxonomies, Classifications, and Categories
    Type
    Standard Barrel Copper Lug
    Category Description
    Comp & Mech Lugs and Butt Splices
    Packaging
    Weight
    0.13 lb/EA
    Weight per each
    0.125
    Carton
    50
    Package
    500
    Uses, Certifications, and Standards
    standard
    UL E9809
    Help Improve Our Data
